48
CAUTION: If the light does not turn
off right after you start the
engine ,stop the engine imediatly.
Check engine oil level. Refill if
necessary. If the oil level is good, see
an authorized Lil Pick Up ATV dealer.
Do not use the vehicle until repaired.
(5) Engine speed indicator
(6) Fuel indicator
When this indicator is ON, it
indicates
an engine fault code, look for a
message
at the LCD display.
When this indicator blinks, it
indicates
that the LIMP HOME mode is
activated.
Refer to TROUBLESHOOTING
section for more details.
(7) Neutral position indicator
(8) Trip meter indicator
(9) Time indicator
(10) 2WD/4WD indicator
When this indicator is ON, it
indicates the 4WD systemis
activated.
(11) Engine Temperature
When this indicator light is ON, it
indicates the engine is overheating. If
engine overheats, stop engine. See
an authorized Lil Pick Up ATV dealer.
Do not use the vehicle until repaired.
A. MODE button
Pressing the MODE (M) button will
scroll through the functions of the
main digital display.
B. SET/RESET button
Pressing the SET (S) button will
scroll through the functions of the
secondary digital display.
Supplementary instruction
Neutral (GREEN)
When lit, it indicates the transmission
is in neutral position.
Right-turning indicator
light(GREEN)
When this indicator light is flashing, it
is for turning right.
