SPECIFICA
TIONS
Item
Parameter
Dimensions
Long
Short
Overall
length
2450mm
2298mm
Overall
width
1246mm
1246mm
Overall
height
1440mm
1335
mm
Wheelbase
1500mm
1348mm
Ground
c
learance
255mm
255mm
Engine
T
ype
650cc
T
wo-cylinder
,
4-s
troke,SOHC,
water
cooling,
800cc
T
wo-cylinder
,
4-s
troke,SOHC,
water
cooling,
1000cc
T
wo-cylinder
,
4-s
troke,SOHC,
water
cooling,
Number
o
f
valves
8(mechanical
adjustment)
Cylinder
diameter
650cc
82mm
800cc
91
mm
1000cc
91
mm
Piston
stroke
650cc
61.5
mm
800cc
61.5
mm
1000cc
75mm
Compression
ratio
650cc
10.3
：
1
800cc
10.3
：
1
1000cc
10.5
：
1
Displacement
650cc
650cc
800cc
800cc
1000cc
976cc
90
92
