OEC COMPACT 7600 Series - C-Arm Cable Routing;Repair; C-Arm Cable Routing;Repair, p. 1, 7-97

B100
BOARD
MONOBLOCK
END
II/CAMERA
END
UNUSED RIBBON CABLE (10 WIRES)
RIBBON CABLE B100 ST4
TO FILTER BOARD X3
RIBBON CABLE - B100 ST3
TO B212 ST1
ST3
ST4
TO FILTER BOARD X3
16WIRES ALL USED
TO ST1 ON B212 BOARD
10 OF 16 WIRES USED
6 FREE - WIRES 15-20
Page 1 of 3
For Reference Only
C-ARM CABLE
ROUTING/REPAIR
7/29/97
C_CABLE.DS4
COMPACT / SERIES 7600
6 WIRES FREE
UNUSED10WIRE
RIBBON CABLE
C-ARM
