INSTRUCTIONS OJ-DV | Technical specifications
25. Technical specifications
Type DV-1005 DV-1007 DV-1011 DV-1013 DV-3015 DV-3024 DV-3030 DV-3040 DV-3055 DV-3065 DV-3075 DV-3110 DV-3150
Enclosure H1 H1x H3 H4 H5
Power size kW 0.5 0.75 1.1 1300 1.5 2.4 3.0 4.0 5.5 6.5 7.5 11 15
Eciency % > 94% > 96,5% > 96,5% > 97%
Power supply
Voltage VAC 1 x 230 VAC 50/60 Hz +/-10% 3 x 400 VAC 50/60 Hz +/-10%
Supply current at max. load A 3.0 4.4 6.5 8.5 3.1 5.0 6.3 8.4 11.5 13.6 15.7 24.4 33
Power factor
(cos-phi) at max. load
> 0.99 (Active PFC) > 0.9
Motor output
Nominal motor power (on shaft) *1 kW 0.5 0.8 1.15 1.3 1.5 2.4 3.0 4.0 5.5 6.5 7.5 11 15
Frequency Hz AC motor: 0-120 | PM motor: 0-400
Max. output voltage Vrms 3 x 0 - 250 VAC 3 x 0 - 364 VAC
Max. output current Arms 2 3.2 4.5 5.2 4.5 6.4 8.0 10.0 12.0 15.0 19.0 27 35.0
Protection
Max. fuse A 16 32
Motor output Short-circuit protected between phases
Motor Protected by current limit
Impulse protection Protected against transient voltages by VDR
Over-voltage protection Yes, 400 V (PTC) Yes, 565 V
Overload protection Current and temperature overload protection
Environment
Operating temperature °C -40°C to +50°C
Starting temperature °C -40°C to +50°C
Storage temperature °C -40°C to +70°C
Dimensions mm 185 x 230.5 x 90 mm
185 x 265
x 125 mm
185 x 265 x 100 mm 220 x 294 x 107 mm 244 x 399 x 144 mm
Protection rating IP 54 & 65
Enclosure material Aluminium
Front cover Plastic
Weight kg 2.0 3.6 3.0 3.9 9.5
Humidity % rh 10-95% rh, non-condensing
Surface Corrosion resistant to EN/ISO 12944-2:1998 Category C4
Air flow / cooling
Turbulent air speed of min. 3 m/s to achieve max. output power at max. ambient temperature.
Turbulent air speed below 3m/s and higher ambient temperature might lead to reduced output power.
(3m/s turbulent air speed is equivalent to 6,5m/s laminar air speed)
Interfaces
Digital communication MODBUS RTU RS485 (baud rate: 9.6, 19.2, 38.4, 115.2 Kbaud)
Digital communication Slave 2 x RJ12 & 2 x spring terminals
Digital communication Master 1 x RJ12 connection
Analogue In1 0-10 VDC, 100% @ 9.5 V DC +/-2%
Analogue Out1 +10 VDC
Digital In1 Start/stop with internal pull-up
Digital In2 Alarm reset
Digital Out1 Tacho: 1 pulse/revolution | Alarm/running signal
Green LED Lit: Power connected | Flashing: Active communication
Red LED Flashing: Alarm but still running | Constantly lit: Critical alarm - stop motor
Features
Technology Sinusoidal back-EMF signal controlled via FOC (Field Oriented Control)
Flying start Yes, < 30% of max. speed
Ramp-up time sec. 15-300
Ramp-down time sec. 15-300
Alarm Yes
Alarm reset Via digital input, MODBUS or powering down for more than 60 seconds
Fan stop sec. The braking system stops the fan as quickly as possible. Braking time will depend on the inertia of the fan.
Service data log Operating hours, alarms, loads, software version, max. temp., max. motor voltage, max. motor current, max. ripple voltage, max. ripple current
Software updating Yes, via serial interface
Motor parameters Preprogrammed by OJ or on-site configuration
Fire mode Nominal power for 1 hour at 70°C ambient temperature
Field weakening Yes
Short-circuit protection Yes
Integrated EMC filters Yes
Approvals
EMC EN 61800-3 (C1 & C2)
LVD EN 61800-5-1
Product standard EN 61800 Part 2
RoHS Directive Yes
Product approvals CE
Data are valid at: nominal supply voltage, +25°C and sucient air flow
Note 1: Motor Power Factor = 0.8 and eciency = 90%
