29 > B401/B411/B431
Printing menu settings
The menu settings can be printed as a menu map as follows.
Using the Online button
1. Press the Online button to take the printer off-line.
2. Press and hold down the Online button for at least four
seconds, but less than seven seconds.
3. The printer prints a list of the menu settings and a demo
print page. See “Online button” on page 16.
Using the Configuration Tool
1. Select Start > All Programs > Okidata >
Configuration Tool and select the Configuration Tool.
2. Click the B411 icon in the left panel.
3. Click the Device Setting tab.
4. Click the MENU SETTING button.
5. Click USER MENU.
6. Click INFORMATION MENU.
7. Click the EXECUTE button beside PRINT MENU MAP.
The Menu Map prints.
TONER (n.nK) REMAINING nnn
%
An indication of how much
toner is left in the cartridge.
ITEM DEFAULT REMARKS
