16 > B411/B431 Operator Panels
LCD
The LCD (3) has two rows of up to 16 alphanumeric digits,
displaying print status and error messages.
Online button
The primary functions of the Online button (4) are activated by
pressing the switch momentarily and releasing. The primary
functions are as follows:
• Turning the printer off-line.
• Turning the printer on-line (ready).
• Resuming printing after page overflow.
• Interrupting data processing when the printer is receiving
and processing data.
• Resuming data processing.
The secondary functions of the Online button are activated after
turning the printer off line, then pressing and holding the switch
for four seconds before releasing. The secondary functions are as
follows:
• Printing the demo and menu pages.
• Printing any data held in the buffer after printing has been
cancelled.
The other functions of the Online button are activated after
turning the printer off line then pressing and holding the switch
for seven seconds before releasing. The other functions are as
follows:
• Printing a cleaning page.
Note
Demo and menu pages can also be printed using the
printer’s Configuration Tool.
