- 26 -
About the Options
1
Setup
Installing a Hard Disk
1 Turn off your printer, and then unplug all
the cables from the printer.
Reference
● "Turning Off the Power" P.29
2 Open the access cover (1) on the right
side of the printer.
1
3 Loosen the screw to remove the metal
plate (2).
2
4 Make sure the LED (3) indicated by the
arrow is unlit. If it is lit, wait until it
turns off.
3
5 Attach a hard disk (4), and fasten two
screws to secure it.
4
6 Plug the white connector (5) of the hard
disk rst into the printer then plug the
other connector (6) into the printer.
5
6
To Next Page
