C5800 Ldn User’s Guide
Replace the Belt Unit • 73
Replace the Belt Unit _______________
REPLACE BELT
355: BELT LIFE
The belt unit is located under the four image drums.
1. Press the cover release and open the top cover fully.
WARNING!
If the printer has been powered on, the fuser is
HOT. This area is clearly labelled. Do not touch it.
To Next Page
