Replacing the Transfer Belt Unit ____
The belt unit is located under the four image drums.
Switch off the printer and allow the fuser to cool for about
10 minutes before opening the cover.
1. Press the cover release and open the printer’s top cover
fully.
2. Note the positions of the four toner cartridges (a) and image
drums (b). It is e
ssential that they go back in the same order.
WARNING!
If the printer has been powered on, the fuser will be
hot. This area is clearly labelled. Do not touch.
