Oki C9800hdn Utility Guide

C9800 Utilities Guide
Print Job Accounting Utility • 46
Server Software
Pull-Down Menus
Printer Menu
Add a Printer Register a new printer.
Manages multiple
printers as a group …
Set up multiple registered printers as a group.
Delete a Printer/Printer
Group
a
a. Before running, select the subject printer from the “Printer Tree” on the left
side of the window.
Delete a registered printer or group of printers.
Change a Printer Group Add or delete registered printers from a group.
Start/End Log
a
Start/end the process of acquiring information for logs
from the printer at the set interval time.
Acquire a Log
a
Acquire a print log saved in the printer.
b
b. Select Log Menu → Refresh Display to update the information on the log
pane after having run this menu.
Setting the Time
a
Set the present time in the printer.
c
c. Only do this if the printer has been turned on and off between the acquisition
of logs. If the printer has been turned on and off, the correct time will not set
in the printer until the next time printer logs are acquired.
Define Fees … Set up and select fees.
Properties … Set the printer properties.

Oki C9800hdn Specifications

Performance

print speed color	36 ppm
print speed mono	40 ppm
time to first page color	10.5 sec
time to first page mono	9 sec
warm-up time	110 sec
resolution	1200 x 1200 dpi
processor	1 GHz
duty cycle	150, 000 pages/month

Memory

standard ram	1, 024 MB
flash memory	4 MB
hard disk drive	20 GB

Paper Handling

standard input	760 sheets
optional input	2nd/3rd universal tray (530 sheets each)
maximum capacity	2, 880 sheets
paper sizes supported	up to 12.9" by 47.24"
paper weight trays 1-5	17 lb.–57.5 lb. bond
duplex printing	standard on C9800hdn

Power and Acoustic Noise

power consumption typical	750W
power consumption peak	1500W
power consumption idle	200W
acoustic noise operating	54dB(A)

Weight and Dimensions

size	25.8" x 24.4" x 18.2"
weight	152 lb.
