Oki MB770 - Page 47

45372301TH Rev.2
4-21 /
Oki Data CONFIDENTIAL
(5) Remove 2 screws and take off the Paper
support F ASSY [9].
Fig. 4-51
(6) Remove 3 screws and 2 connectors [10],
remove the ejector motor ASSY [11].
Fig. 4-52
Remark:
Be sure to attach the 2 connectors previ-
ously.
Fig. 4-53
[9]
[11][10]
