Oki MICROLINE 8810 Setup Guide

10
8. Position the continuous forms stack below the
printer with no more than about 1 inch (3 cm)
offset (
1 ).
Tearing Off Printed Continuous Forms
9. With the SEL light on, press SHIFT.
The continuous forms move forward onto the
stacker.
10. Tear off the printed form along the perforation.
11. Press SHIFT.
The forms move back into the printer, ready for
printing the next document.
Removing Continuous Forms
1. Follow the steps above to remove the printed
portion.
2. Press SEL.
3. Press LOAD.
The forms move back to the tractors.
4. Lift the platform and remove the forms from the
tractors.
5. Lower the platform.
Step 5:
Connect to the Computer
Caution!
Do not connect both the USB and parallel
ports at the same time.
USB Port
Note
No USB interface cable is supplied with the
printer. Use a USB cable that is compatible with
USB specification 2.0.
1. Turn off the printer.
2. Connect the USB cable to the USB port on the
printer.
3. Secure the cable in one of the channels (
1 )
molded into the housing on either side at the back
of the printer to keep it out of the way.
4. Connect the USB cable to the USB port on the
computer.
5. Turn on the printer.
F3_02_c

Oki MICROLINE 8810 Specifications

General

Color	No
Built-in barcodes	EAN13, PostNet, UPC-A, UPC-E
Maximum number of copies	8 copies
Fonts included	5
Media thickness	0.48 mm
Dimensions (WxDxH)	598 x 397 x 235 mm
Power requirements	120V-240V (±10%, 50Hz/60Hz)
Connectivity technology	Wired
Compatible operating systems	Windows Vista 32/64, XP, 2000, 98, NT 4.0, 2003 Server
Print direction	Bi-directional
Maximum duty cycle	24000 pages per month
Mean time between failures (MTBF)	10000 h
Sound pressure level (printing)	55.5 dB
Power consumption (standby)	25 W
Power consumption (typical)	120 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	30 - 85 %
