Oki MICROLINE 8810 Setup Guide

6
13. Push the display panel back to its original
position.
13. Close the cover.
Caution!
If the cover does not close easily, do not
force it
. The right end of the ribbon
cartridge is not properly seated in the
printer. Open the cover and reseat it. Then
reclose the cover.
Install the Stacker
With the flat edge toward the printer and the frosted
side up, slide the stacker into the channels at either
end of the support, pushing it in as far as it will go.
Remove the Protective Film
Peel the protective plastic film off the viewing area on
the cover.
F2_03_cl
ose_cove
Remove_Prote
ctive_Plastic.jp
g

Oki MICROLINE 8810 Specifications

General

Color	No
Built-in barcodes	EAN13, PostNet, UPC-A, UPC-E
Maximum number of copies	8 copies
Fonts included	5
Media thickness	0.48 mm
Dimensions (WxDxH)	598 x 397 x 235 mm
Power requirements	120V-240V (±10%, 50Hz/60Hz)
Connectivity technology	Wired
Compatible operating systems	Windows Vista 32/64, XP, 2000, 98, NT 4.0, 2003 Server
Print direction	Bi-directional
Maximum duty cycle	24000 pages per month
Mean time between failures (MTBF)	10000 h
Sound pressure level (printing)	55.5 dB
Power consumption (standby)	25 W
Power consumption (typical)	120 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	30 - 85 %
