Oki ML3410 User Manual

Form Tear Off (continuous form paper only)
Form Tear Off (continuous form paper only)
This feature lets you remove a printed page from the printer without wasting paper. Activate it by
changing the setting for the Form Tear Off menu selection to 500ms, 1 sec, or 2 sec. (See Chapter 3 (
)
for details on the printer menu.)
Note
Keep in mind that there are separate menu groups for each of the three possible paper paths. Be sure to
activate the Form Tear Off selection for the one you are using, rear feed or bottom feed.
After you load paper and press the FORM FEED button, the paper will advance past the printing (top of
form) position to the tear bar position. It stays in this position until the printer receives data; the paper
then moves back down for printing. A few seconds after printing stops, the paper moves back to the tear
bar
so you can tear it off without feeding an extra sheet of paper.
You can check the top of form position by pressing the TEAR button. Release the button to return to the
tear off position.
ML3410 ( 96-02-07 )

Oki ML3410 Specifications

Print Specifications

printhead	9 pin
print speed at 10 cpi	HSD 550 cps, Utility 417 cps, NLQ 104 cps
graphics resolution	1445216 dpi maximum

Paper Handling

paper weight	12 to 24 lb
paper thickness top feed	0.36 mm (0.014 inches) maximum
paper thickness bottom feed	0.50 mm (0.020 inches) maximum

Operating Environment

operating temperature	50 to 104 degrees F (10 to 40 degrees C)
storage temperature	14 to 122 degrees F (-10 to +50 degrees C)
humidity	20 to 80% RH

Electrical Requirements

voltage	120 volts, +5.5%/-15% 220/240 volts, ±10%
frequency	50/60 Hz, ±2 Hz
power idling	30 watts
power operating	75 watts

Weight and Dimensions

width	25-1/4 inches (540 mm)
depth	19 inches (483 mm)
height	15 inches (203 mm)
weight	63 lbs. (25.4 kg)
