Appendix C
Serial Cable Pinout
Serial Cable Pinout for the PM3410
This appendix is designed to help you make a serial cable to connect your printer to your computer.
Please do not attempt to make a cable unless you're experienced in doing so. The table below
explains the signals from the printer's end. You must read you computer documentation to
determine the requirements on your computer's end. Your PM3410 printer requires a
shielded
RS-232C cable which is
¨ UL and CSA approved
¨ no more than 50 feet in length
and has
¨ Cannon DB-25P plug (or equivalent) with 25 pins
¨ Cannon DB-C2-J9 (or equivalent) connector shell
Serial Interface Signal Requirements
Pin Signal
Symbol
Direction Description
1
Protective
Ground
PG Ground Connected to the
printer frame.
2 Transmit Data TD From printer Serial data
transmitted to the
system
3 Receive Data RD To printer Serial data received
by the printer
4 Request to Send RTS From printer Always set to low
(mark)
6 Data Set Ready DSR To printer Indicates that data
can be sent
7 Signal Ground SG Ground Ground
11 Supervisory Send
Data
SSD From printer Indicates that printer
is
not ready to
receive data
20
Data Terminal
Ready
DTR From printer Indicates that printer
is not ready to
receive data
