Oki ML3410 User Manual

Changing Paper Types
Changing Paper Types
You don't have to remove continuous forms paper in order to print a single sheet. With the touch of
a button you can switch from one type of paper to another.
To change from continuous forms to single sheets:
1. Remove any printed pages from the printer.
2. Press the PARK button to retract the continuous forms paper from the paper path.
3. Move the paper lever to the single sheet position if you're switching from rear feed.
4. Follow the instructions under Single-Sheet Paper for loading single sheets.
To change back to continuous forms:
1. Remove any single-sheet paper in the printer.
2. Move the paper lever to the continuous forms position if youre switching to rear feed, leave it set
for single sheets if you're switching to bottom feed.
3. Lower the paper support.
4. Press the FORM FEED button to feed continuous forms paper into the printer.
ML3410 ( 96-02-07 )

Oki ML3410 Specifications

Print Specifications

printhead	9 pin
print speed at 10 cpi	HSD 550 cps, Utility 417 cps, NLQ 104 cps
graphics resolution	1445216 dpi maximum

Paper Handling

paper weight	12 to 24 lb
paper thickness top feed	0.36 mm (0.014 inches) maximum
paper thickness bottom feed	0.50 mm (0.020 inches) maximum

Operating Environment

operating temperature	50 to 104 degrees F (10 to 40 degrees C)
storage temperature	14 to 122 degrees F (-10 to +50 degrees C)
humidity	20 to 80% RH

Electrical Requirements

voltage	120 volts, +5.5%/-15% 220/240 volts, ±10%
frequency	50/60 Hz, ±2 Hz
power idling	30 watts
power operating	75 watts

Weight and Dimensions

width	25-1/4 inches (540 mm)
depth	19 inches (483 mm)
height	15 inches (203 mm)
weight	63 lbs. (25.4 kg)
