Oki ML3410 User Manual

Printing Envelopes with the CSF
Printing Envelopes with the CSF
You can use #10 envelopes (standard business size) in your CSF3001 and in the front bin only of
the CSF 3002.
Be sure to adjust the head gap lever (5-9) and push the envelope lever back.
Load envelopes with the flaps facing down and toward the front of the printer. Set the envelope
lever to the rear.
For best results, avoid printing on areas where the flap overlaps the envelope. Printing may be
uneven in places where the envelope varies in thickness.
ML3410 ( 96-02-07 )

Oki ML3410 Specifications

Print Specifications

printhead	9 pin
print speed at 10 cpi	HSD 550 cps, Utility 417 cps, NLQ 104 cps
graphics resolution	1445216 dpi maximum

Paper Handling

paper weight	12 to 24 lb
paper thickness top feed	0.36 mm (0.014 inches) maximum
paper thickness bottom feed	0.50 mm (0.020 inches) maximum

Operating Environment

operating temperature	50 to 104 degrees F (10 to 40 degrees C)
storage temperature	14 to 122 degrees F (-10 to +50 degrees C)
humidity	20 to 80% RH

Electrical Requirements

voltage	120 volts, +5.5%/-15% 220/240 volts, ±10%
frequency	50/60 Hz, ±2 Hz
power idling	30 watts
power operating	75 watts

Weight and Dimensions

width	25-1/4 inches (540 mm)
depth	19 inches (483 mm)
height	15 inches (203 mm)
weight	63 lbs. (25.4 kg)
