Oki ML3410 User Manual

DOS Commands for Printing Text Files
DOS Commands for Printing Text Files
¨ PRINT filename
¨ TYPE filename > devicename
¨ COPY filename devicename
If you've used a word processor or other software package to prepare your document, it's usually easiest
to use that packages print commands to print it. This is particularly true if the software lets you control a
documents appearance, page length, margins, printing features, and so on.
However, if your software doesnt control these kinds of features, it's just as easy to print using DOS
commands. Some packages even have a print to disk feature, so you can save the file on a disk in a
format that DOS can later read and send to the printer.
ML3410 ( 96-02-07 )

Oki ML3410 Specifications

Print Specifications

printhead	9 pin
print speed at 10 cpi	HSD 550 cps, Utility 417 cps, NLQ 104 cps
graphics resolution	1445216 dpi maximum

Paper Handling

paper weight	12 to 24 lb
paper thickness top feed	0.36 mm (0.014 inches) maximum
paper thickness bottom feed	0.50 mm (0.020 inches) maximum

Operating Environment

operating temperature	50 to 104 degrees F (10 to 40 degrees C)
storage temperature	14 to 122 degrees F (-10 to +50 degrees C)
humidity	20 to 80% RH

Electrical Requirements

voltage	120 volts, +5.5%/-15% 220/240 volts, ±10%
frequency	50/60 Hz, ±2 Hz
power idling	30 watts
power operating	75 watts

Weight and Dimensions

width	25-1/4 inches (540 mm)
depth	19 inches (483 mm)
height	15 inches (203 mm)
weight	63 lbs. (25.4 kg)
