Oki ML3410 User Manual

Changing the Default Printer Port
Changing the Default Printer Port
If your system doesn•t use LPT1: to connect the printer to the computer, you can specify which port DOS
should use as its default. At the DOS prompt, enter the appropriate MODE command(s).
¨ For a serial interface, first enter:
MODE COM1:9600,N,8,1,P Then enter:
MODE LPT1:=COM1: ¨ For a parallel interface, enter:
MODE LPT2:
If your serial interface is COM2:, replace COM1: in the commands shown above with COM2:. Likewise,
your parallel interface may be LPT3:, in which case, change the MODE command to MODE LPT3:.
To avoid having to reenter the MODE command(s) every time you reset the computer, enter them in your
computers AUTOEXEC.BAT file. To create an AUTOEXEC.BAT file or edit an existing one, use a text
editor or a word processor in a mode that allows you to create ASCII text files. If youre editing your
systems AUTOEXEC.BAT file, be sure not to change or delete anything already in the file.
For more information on working with AUTOEXEC.BAT files, see your DOS manual.
ML3410 ( 96-02-07 )

Oki ML3410 Specifications

Print Specifications

printhead	9 pin
print speed at 10 cpi	HSD 550 cps, Utility 417 cps, NLQ 104 cps
graphics resolution	1445216 dpi maximum

Paper Handling

paper weight	12 to 24 lb
paper thickness top feed	0.36 mm (0.014 inches) maximum
paper thickness bottom feed	0.50 mm (0.020 inches) maximum

Operating Environment

operating temperature	50 to 104 degrees F (10 to 40 degrees C)
storage temperature	14 to 122 degrees F (-10 to +50 degrees C)
humidity	20 to 80% RH

Electrical Requirements

voltage	120 volts, +5.5%/-15% 220/240 volts, ±10%
frequency	50/60 Hz, ±2 Hz
power idling	30 watts
power operating	75 watts

Weight and Dimensions

width	25-1/4 inches (540 mm)
depth	19 inches (483 mm)
height	15 inches (203 mm)
weight	63 lbs. (25.4 kg)
