Oki ML3410 User Manual

Of course, you can also use the CHR$ function to output printable characters; for instance, CHR$(65)
represents the letter A. However, its usually easier to type letters, numbers and punctuation marks, and
your BASIC programs will be much easier to read if you use literal characters, enclosed in quotes,
wherever possible.
Some printer commands expect you to supply a numerical value, representing tab stops, line spacing,
etc. In most cases, values are entered as literal or ASCII characters. For example, using the Microline
standard ESC %C command to set a left margin of one inch (120/120 inch), you would enter the following
line in BASIC:
LPRINT CHR$(27);"%C";"120"
A few commands require that you enter numerical values as the argument to a CHR$ function. The
descriptions of the commands in the appendices will tell you which format to use.
ML3410 ( 96-02-07 )

Oki ML3410 Specifications

Print Specifications

printhead	9 pin
print speed at 10 cpi	HSD 550 cps, Utility 417 cps, NLQ 104 cps
graphics resolution	1445216 dpi maximum

Paper Handling

paper weight	12 to 24 lb
paper thickness top feed	0.36 mm (0.014 inches) maximum
paper thickness bottom feed	0.50 mm (0.020 inches) maximum

Operating Environment

operating temperature	50 to 104 degrees F (10 to 40 degrees C)
storage temperature	14 to 122 degrees F (-10 to +50 degrees C)
humidity	20 to 80% RH

Electrical Requirements

voltage	120 volts, +5.5%/-15% 220/240 volts, ±10%
frequency	50/60 Hz, ±2 Hz
power idling	30 watts
power operating	75 watts

Weight and Dimensions

width	25-1/4 inches (540 mm)
depth	19 inches (483 mm)
height	15 inches (203 mm)
weight	63 lbs. (25.4 kg)
