REMARK
In classified areas, the installation must comply with the standards in force.
- Connections on MX48 unit: see Fig. 21.
IMPORTANT
All intrinsic safety installations must be APPROVED as a whole assembly by an approved
organization (DRIRE, etc.).
OLDHAM “INTRINSIC SAFETY” BARRIERS
Type of IS
barrier
Reference Specific features OLDHAM box
reference
Z787 / EX 6184703 To be fitted on DIN
RAIL
MTL787S+ 6797100 To be fitted in an
approved box:
MANDATORY
For 2 clippers 6797192
For 5 clippers 6797547
For 12 clippers 6797101
2.3.8. Other detectors with standardized current output
Any detector (with 2 wires or 3 wires) that can be supplied with power between 19 V DC and 32 V
DC and that supplies a standardized current (signal) of between 4 and 20 mA can be connected to
the MX48 unit.
The connection requirements are identical to those for the corresponding OLDHAM detectors (see
Fig. 22).
2.3.9. Parking application
CTX300 "Co parking" toxic gas detectors can be fitted in parallel when a mean gas concentration is
to be obtained. The detectors must, imperatively, be located in the same area. In this case, a
maximum of five detectors can be connected (see Fig. 23).
