Chapter 2 | Ranges
OLC 100 and OLCT 100 ranges
The OLC 100 range is reserved for the detection of explosive vapor by using a
Wheatstone bridge sensor.
The OLCT 100 range of detectors is provided with an amplifier producing a 2 or 3
wire 4-20 mA analog output. These are transmitter detectors and, therefore, the
letter "T".
(1) Requires the use of a Zener barrier
(2) Sensor can be remote up to 5, 10, or 15 meters using a high temperature cable
(3) mV bridge output, 3 wires
EC : Electrochemical sensor
SC : Semi-conductor sensor.
LEL : Catalytic bead
AP : Poison resistant
Table 1 : com parison of OLC 100 and OLCT 100 series detectors
OLC 100
OLCT 100 XP
OLCT 100
XPIR
OLCT 100 IS
OLCT 100 HT
Features
Explosion
proof
Explosionproof
Explosionproof
Intrinsically
safe (1)
Explosionproof
(2)
Detection of
explosive
gases
Catalytic
sensor (VQ1)
Catalytic
sensor (VQ1
or AP 4F) or
semi-
conductor
Catalytic
sensor
high
temperature
Detection of
toxic gases
EC
Or SC
Infrared
sensor
EC
Detection of
oxygen
EC
EC
Detection of
CO
2
Infrared
sensor
4-20 mA
output
(3)
2 w ires for EC
3 w ires for SC
3 w ires for LEL
3 w ires
2 w ires
3 w ires
