Oldham OLCT 100 XP User Manual

10 – Technical specifications
55
Weight :
OLC 100 : 0.950 kg
OLCT 100 XP HT : 1.8 kg
OLCT 100 XP LEL : 1.0 kg
OLCT 100 XP IR : 1.1 kg
OLCT 100 XP EC : 1.1 kg
OLCT 100 XP SC : 1.1 kg
Materials:
Epoxy painted aluminum. 316 Stainless Steel in option
Catalytic sensor (OLCT 100 XP)
Common characteristics
Measurement range :
0 – 100% LEL
Measurement principle :
catalytic
Accuracy :
see table below
Temperature range :
see table below
Relative humidity :
0 to 95% RH (non-condensing relative humidity)
Pressure :
atmospheric ± 10%
Response time :
T
50
= 6 seconds. T
90
= 15 seconds for Methane
Lifetime (typical) :
48 months
Storage conditions :
-50 to 70°C, 20 to 60% RH, 1 bar ± 10%, 6 months
maximum
Warm-up time (max) :
2 hours to first sw itching on pow er
Specific characteristics
Type of sensors
Accuracy
Operating
temperature
range
Anti-poison sensor
4F (unmarked
sensor)
1% LEL between 0- 70 %LEL
2% of the measurement betw een 71 and 100%
LEL
-40 to +70°C
VQ1 sensor
(sensor with
identifying mark)
1% LEL betw een 0- 70 %LEL
OLCT 100 : 2% of the measurement between 71 and
100% LEL
OLC 100 : 5% of the measurement between 71 and
100 % LEL
-40 to +70°C
VQ1 sensor, high
temperature
assembly
1% LEL between 0-70%LEL
2% of the measurement betw een 71 and 100%
LEL
-20 to +200°C
