When an anti-poison 4F type sensor is used (only available for OLCT 100), the
coefficients are as follows:
Gas
Chemical
Formula
LEL %
LSE
%
Vapor
density
CH
4
Coef
C
5
H
12
Coef
H
2
Coef
Acetone
C
3
H
6
O
2.15
13.0
2.1
1.8
0.9
1.1
Acety lene
C
2
H
2
2.3
100
0.9
1.4
0.7
Ammoniac
NH3
15.0
30.2
0.6
1.0
0.5
Benzene
C6H6
1.2
8.0
2.7
2.10
1.05
n-Butane
C4H10
1.5
8.5
2.0
1.8
0.9
Ethane
C2H6
3.0
15.5
1.0
1.4
0.7
Ethanol
C2H6O
3.3
19.0
1.6
1.6
0.8
Ethylene
C2H4
2.7
34.0
1.0
1.4
0.7
n-Hexane
C6H14
1.2
7.4
3.0
2.85
1.4
HFO-1234yf
6.2
12.3
1.25
0.55
Hydrogen
H2
4.0
75.6
0.07
1.0
Isopropanol
C3H8O
2.15
13.5
2.1
1.8
0.9
JP-4
3.0
1.5
JP-5
3.1
1.55
JP-8
3.2
1.6
Methane
CH4
5.0
15.0
0.55
1.0
Methanol
CH3OH
5.5
44.0
1.1
1.35
0.65
n-Pentane
C5H12
1.4
8.0
2.5
2.0
1.0
Propane
C3H8
2.0
9.5
1.6
1.6
0.8
Styrene
C8H8
1.1
8.0
3.6
2.4
1.2
Toluene
C7H8
1.2
7.0
3.1
2.5
1.25
Xylene
C8H10
1.0
7.6
3.7
2.4
1.2
Cells with a grey background: gases recommended for calibrating the detector
Table 3 : Calibration coefficients of explosive gases for catalytic detectors
with a 4F sensor.
Example
Calibration of an "acetone" detector with a calibration gas of 1% volume butane
Value to be displayed:
1% (𝑖𝑛𝑗𝑒𝑐𝑡𝑒𝑑 𝑏𝑢𝑡𝑎𝑛𝑒)
1.5% (𝐿𝐸𝐿 𝑏𝑢𝑡𝑎𝑛𝑒)
x 100 x 0.90 (butane/acetone coefficient) = 60 % LEL
Note:
LEL values vary according to the source.
Coefficients are accurate to ± 15%.
