p.27
12.2 Removing the U-pin
Removing the U-pin
When replacing a leaking valve, place the service holder on the OligoMaker. Tighten the
two screws which are placed behind the service holder. Place the Valve Manifold on the
service holder.
To remove the Alu-cover, untie the two screws. Place it behind the row of valves.
Remove the U-pin with the universal tool.
