Contents of the Shipping Container
1. Oliver Wide Belt Sander
Toolbox Contents
4. Leveling Pads
4. M14x45 Hex Cap Bolts
4. M14 Hex Nuts
4. Handles (doors)
1. Handle (raising table)
1. T-Handle Hook
1. Phillips Head Screwdriver
1. Flat Head Screwdriver
4. Open End Wrenches
1. Closed End Wrench
6. Hex Angle Wrenches
2. Cans of Touch-Up Paint
Uncrating the Machine
Uncrate the machine and inspect the unit for
signs of shipping damage. If damage is found,
contact your dealer immediately. For protection
against shifting during transport, the base of the
wide belt sander was bolted to the shipping
pallet in four places (A, Figure 1). Remove
these bolts. Retain all packaging materials in
case it becomes necessary to ship the machine
back to the dealer, or to another site.
Machine Preparation and Setup
! WARNING
The equipment used to lift this machine must
have a rated capacity at, or above the weight
of the sander. Failure to comply may cause
serious injury!
A forklift can be used to lift the machine from
underneath. The sander can also be lifted from
over head using the four lifting eyelets (B, Figure
1).
The sander must be positioned on a smooth,
level surface. Install the leveling feet under the
four corner flanges of the wide belt sander, as
shown in Figure 2.
6
