797-32C BREAD SLICER
0797S20088 0-1
INDEX
Section Description
Document No. Page No.
SAFETY INSTRUCTIONS ------------------------------- 0797S20063 --------------------- 1-1
DESCRIPTION/SPECIFICATIONS -------------------- 0797S20089---------------------- 2-1
Description -------------------------------------------------------------------------------------- 2-1
Specifications----------------------------------------------------------------------------------- 2-1
INSTALLATION INSTRUCTIONS --------------------- 0797S20090 --------------------- 3-1
Removing the Slicer from the Shipping Skid ------------------------------------------- 3-1
Installing Optional Casters ----------------------------------------------------------------- 3-2
OPERATING INSTRUCTIONS ------------------------- 0797S20091 --------------------- 4-1
Using the Slicer’s Holddown --------------------------------------------------------------- 4-1
Adjusting the Slicer for Product Length -------------------------------------------------- 4-1
Adjusting the Outfeed Side Guides on a Standard Outfeed Table --------------- 4-2
Operating a Gravity Feed Slicer ----------------------------------------------------------- 4-3
Using the Last Loaf Pusher ----------------------------------------------------------------- 4-3
TROUBLESHOOTING ------------------------------------ 0797S20092 --------------------- 5-1
The Slicer Will Not Start (Motor is Not Humming) ------------------------------------ 5-1
The Slicer Will Not Start (Motor is Humming) ------------------------------------------ 5-1
Bread Slices Vary in Thickness ----------------------------------------------------------- 5-2
The Blade Frames are Knocking ---------------------------------------------------------- 5-2
The Slicer Vibrates Excessively ----------------------------------------------------------- 5-2
The Bread is Cutting Slowly or is Being Damaged ----------------------------------- 5-2
MAINTENANCE -------------------------------------------- 0797S20093 --------------------- 6-1
Cleaning ----------------------------------------------------------------------------------------- 6-1
Lubrication -------------------------------------------------------------------------------------- 6-1
Removing the Blade Frames --------------------------------------------------------------- 6-2
Changing the Blades ------------------------------------------------------------------------- 6-5
Tightening the Belt ---------------------------------------------------------------------------- 6-7
Replacing the Belt ----------------------------------------------------------------------------- 6-9
Adjusting the Blade Frames When Slices Vary in Thickness --------------------- 6-10
Adjusting the Clearance Between the Blade Frames ------------------------------- 6-11
RECOMMENDED SPARE PARTS -------------------- 0797S20070 --------------------- 7-1
REPLACEMENT PARTS SECTION
MAIN FRAME & ROCKER ------------------------------ 0797S20071 --------------------- 8-1
Drawing ------------------------------------------------------------------------------------- 8-1
Parts List ----------------------------------------------------------------------------------- 8-2
