59
7
3
Remove the new drum cartridge from the protective bag and
remove the protective cover from the cartridge. Then gently
install the new drum cartridge.
4
Gently install the toner/developper cartridge. To install the
toner/developper cartridge, see step 5 in "INSTALLING THE
TONER/DEVELOPER CARTRIDGE" (p.10).
5
Close the front cover and then the side cover by pressing the
round projections near the side cover open button. The drum
replacement required ( ) indicator will go out and the start ( )
indicator will light up.
Do not touch the surface of the drum (green portion) of the
cartridge. Doing so may cause smudges on the copies.
When closing the covers, be sure to close the front cover securely and
then close the side cover. If the covers are closed in the wrong order, the
covers may be damaged.
