67
8
C: Misfeed in the transport area
1
Lower the fusing unit release lever.
See "B: Misfeed in the fusing area" (p.66).
2
Open the front cover.
To open the front cover, see "INSTALLING THE TONER/DEVELOPER
CARTRIDGE" (p.10).
3
Rotate the roller rotating
knob in the direction of the
arrow and gently remove
the misfed paper from the
exit area.
4
Raise the fusing unit release lever, close the front cover and
then close the side cover by pressing the round projections
near the side cover open button. The misfeed ( ) indicator will
go out and the start ( ) indicator will light up.
When closing the covers, be sure to close the front cover securely and
then close the side cover. If the covers are closed in the wrong order, the
covers may be damaged.
Roller rotating knob
To Next Page
