Olivetti MB-2 - Document Handling

Y112890-3 Service Manual
1-3
DOCUMENTS THAT CAN BE HANDLED BY THE BASIC MACHINE
• SINGLE FORM
• Width 65 x 245 mm
• Length 297 x 70
• Single sheet thickness 0.07 ÷ 0.28 mm
• Single sheet weight 60 ÷ 160 gr/m
2
• Chemical paper copies n°1+4 (medium weight) LQ: n°1+6
• Carbon paper copies n°1+4 (medium weight) LQ: n°1+6
• PASSBOOK WITH VERTICAL BINDING
• Width max. (open) 241 mm
• Width min. (open) 150 mm
• Length max. 220 mm
• Length min. 85 mm
• PASSBOOK WITH HORIZONTAL BINDING
• Width max. 241 mm
• Width min.150 mm
• Length max. (open) 220 mm
• Length min. (open) 165 mm
• OTHER CHARACTERISTICS
• Max. thickness (open) (in the passport version, the maximum thickness is 5 mm)
• Max. diff. In thickness between pages1,2 mm
• Cover thickness 0,2 to 0,5 mm
• Type of binding permitted: thread seam
• Joining radius of outer corners 3 to 14 mm
DIMENSIONS
Width: 384 mm
Depth: 296 mm
Height: 204 mm
Weight 10.5 Kg
POWER CONSUMPTION During printing: 170 W max (worst performance)
POWER SUPPLY
230 Vac + 10%
50/60 Hz
