Y112890-3 Service Manual
1-7
1 Parallel interface connector 12 Carriage reset photosensor connector
2 Serial interface connector 13
SBI signal connector of the card for MICR
configuration
3 Printhead connector 14 Power unit connector
4 Printhead connector 15
Signal connector for cards for Horizontal Magnetic
and MICR configurations
5 Alignment device photosensors 16
Power and signals connector for Horizontal
Magnetic and MICR configuration cards
6 Console connector 17 Front CIS (scanner) connector
7 Carriage motor connector 18 Rear CIS (scanner) connector
8 Open/close cover sensor connector 19
Connector for USB ports (two at rear) from HUB to
peripherals
9 Paper motor connector 20
USB port connector (on front) from HUB to
peripheral
10
Analogue signal connector of the card for
MICR configuration
21 USB port connector (to host)
11 Services motor connector
