30
P/N 30149, Rev. G [12/15/2016]
Ref. No. Description Part No.
All parts are the same as listed on previous pages for chimney vent Model BML-80B and BMLV-
80B except where noted below.
15 Pouch Gasket (Second gasket required for Direct Vent) 2080175
22
Wire Harness Fan Timer Board Direct Vent 30745
28
Beckett Oil Burner AFII 85 30069
Burner Motor 1/7 HP 3450 RPM PSC 28907
Beckett Clean-cut Oil Pump A2EA6520 29688
Solid State Ignitor 28558
Oil Primary Combustion Control 7505P1530
Air Tube Combination FBX80HGXS 28561
Flame Retention Head (FB3) 28533
Riello Oil Burner 40BF3 30427
34 Appliance Vent Adapter 5" x 3" 240006904
* Pressure Switch -0.28" WC 30700
* 10 Second Bypass Timer GPS00C9X10 (Use with Beckett AFII) 30699
* 25 Second Bypass Timer GPS00C9X25 (Use with Riello 40BF3) 240005182
Parts Listing: Direct Vent Models BML80(BB2U2,BRBU2) and BMLV80(BB2U2,BRBU2)
PARTS LISTING
