21
SPECIFICATIONS
Module Specification
Motorized Reflected Light
Brightfield/Darkfield
Illuminator
BX-RLAA
Power Source:
Control Box
BX-UCB
Control Source:
Hand Switch
U-HSTR2 or PC
· UIS2 (UIS) (Universal Infinity System) optical system
· Tube magnification 1X, super widefield (FN 26.5) compatible
· Observation method switching: Motorized BF/DF switching
· Aperture iris diaphragm: Motorized opening/closing ( 0.4 to 11.1 mm), centering possible
· Field iris diaphragm: Manual knob opening/closing, centering possible
· Filter slider insertion slots: x 2
· Motorized revolving nosepiece connector provided (Connector position fixed at the factory)
· Available observations: @ Reflected light brightfield
² Reflected light darkfield
³ Reflected light Nomarski DIC
| Reflected light simplified polarized light
· Applicable microscope: BX61
Operating environment · Indoor use.
· Altitude: Max. 2000 meters
· Ambient temperature: 5° to 40°C (41° to 104° F)
· Maximum relative humidity: 80% for temperatures up to 31°C (88°F), decreasing linearly through
70% at 34°C (93°F), 60% at 37°C (99°F), to 50% relative humidity at 40°C (104°F).
· Supply voltage fluctuations; Not to exceed ±10% of the normal voltage.
· Pollution degree: 2 (in accordance with IEC60664)
· Installation/Overvoltage category: II (in accordance with IEC60664)
