Olympus BX-RLAA - Default Chapter; Table of Contents

1 Selecting the Observation Path 2 Centering the Field Iris Diaphragm (FS)
3 Centering the Aperture Iris Diaphragm (AS)
4 Using the Interlocked ND Filter 5 Using the Filters
BX-RLAA
CONTENTS
Correct assembly and adjustments are critical for the microscope to exhibit its full performance. If you are going to assemble the
microscope yourself, please read chapter 9, “ASSEMBLY” (pages 27 to 29) carefully.
IMPORTANT — Be sure to read this chapter for safe use of the equipment. — 1-2
1 SYSTEM DIAGRAM 3
2 NOMENCLATURE OF BX-RLAA 4
3 MOTORIZED REFLECTED LIGHT BRIGHTFIELD/DARKFIELD OBSERVATION PROCEDURE 5-6
4 USING THE CONTROLS OF BX-RLAA 7-11
5 STAGE FOR METALLURGICAL SPECIMENS 12-14
1 Placing the Specimen 2 Using the Y-Axis Movement Lock Lever
6 OBSERVATION METHODS (Using BX-RLAA) 15-20
6-1 Reflected Light Brightfield/Darkfiled Observation ........................................................................................................................................ 15
6-2 Reflected Light Nomarski DIC Observation ................................................................................................................................................. 15-20
6-3 Reflected Light Simplified Polarized Light Observation .......................................................................................................................20
7 SPECIFICATIONS 21
8 OPTICAL CHARACTERISTICS «UIS2 Series» 22-26
9 ASSEMBLY 27-29
