8
BX-UCB/U-HSTR2
TROUBLESHOOTING GUIDE
Under certain conditions, performance of the microscope may be adversely affected by factors other than defects. If a problem
occurs, please review the following list and take remedial action as appropriate. If you cannot solve the problem after checking
the entire list, please contact your local Olympus representative for assistance.
Problem
Cause Remedy Page
a) ERR (Error) indicator blinks.
Module corresponding to the indicator
blinking simultaneously with ERR is not
connected properly.
Connect the motorized module of the
simultaneously blinking indicator prop-
erly.
b) Power cannot be turned on by set-
ting the main switch to “ I ” (ON).
Power cord is unplugged.
Connect the power cord properly.
c) Communication through RS232C
is impossible.
The RS232C cable in use is wrong.
Use the specified RS232C cable.
The RS232C cable is not connected
properly.
Connect it properly.
d) The Hand Switch buttons do not
work or the indicators do not light.
The hand switch is not connected prop-
erly.
Connect it properly.
e) A motorized module does not work
or its indicator does not light.
The motorized module is not connected
properly.
Connect it properly.
f ) The lamp will not light.
The lamp housing connector is not con-
nected properly.
Connect it properly.
The transmitted/reflected light switch of
microscope is set erroneously.
Set to the correct position that you want
to use.
The lamp on-off switch of microscope is
set to OFF.
Set it to ON.
The lamp is blown. Replace the lamp.
g) The U-UCD8A or BX-RLAA is not
functioning normally.
Both modules are connected to the con-
trol box. (It is not permitted to use the U-
UCD8A and BX-RLAA together.)
Unplug the connector of the module
that you do not want to use.
9
10
6
9
10
9
9
–
–
9
–
