NOMENCLATURE
}If you have not yet assembled the microscope, read section 8, “ASSEMBLY” (pages 28 to 30).
Interpupillary distance adjustment scale
(Page 13)
Diopter adjustment ring
(Page 13)
Slider insertion slot
Slide holder (Page 11)
Aperture iris diaphragm ring
(Page 16)
Y-axis knob (Page 12)
X-axis knob (Page 12)
Turret (Page 5)
Brightness adjustment knob (Page 8)
(Lamp voltage adjustment knob)
Field iris diaphragm ring (Page 15)
Marker
U-MARKER
Allen screwdriver
(accommodation position)
Condenser centering screws
Main switch (Page 1)
Voltage indicator LED
Light intensity preset
switch (Page 8)
Light intensity preset
adjustment screw
(Page 8)
Coarse adjustment tension adjustment ring (Page 10)
Filter slider (Page 9)
(accommodation positions)
