10
12. The maximum frame rate according to the resolution of the live image is shown in the table below. The maximum
frame rate is given when the exposure time as shown in the table.
DP22-CU:
Resolution Exposure time (sec) Frame rate (fps)
1920 x 1440 1/27 25
960 x 720 (Draft) 1/27 25
960 x 720 (Binning) 1/27 25
DP27-CU:
Resolution Exposure time (sec) Frame rate (fps)
2448 x 1920 1/16 15
1224 x 960 (Draft) 1/33 30
1224 x 960 (Binning) 1/33 30
13. When observing a specimen which contains little white area, the traceability of auto white balance is deteriorated.
14. When the edge of a non-transmitted object is observed by transmitted illumination under the STM6 (small
measuring microscope), the flare may be noticeable due to the difference in brightness between the transmitted
sections (over-exposure) and non-transmitted sections (under-exposure).
To reduce the flare, set a lower exposure by using the exposure compensation or by setting the exposure manually.
