1 System diagram
} Consult Olympus for the compatible microscope and camera adapter .
* The camera head may not work properly in combination with some PCs. Refer to Olympus website to check the
PCs whose performances in combination use with this system were confirmed.
DP22-CU
/
DP27-CU
Camera head
Camera adapter
Interface cable
PC *
cellSens Standard
software
OLYMPUS Stream
software
DP2-TWAIN
TWAIN driver
(provided only by
downloading from website)
