Page #150 background imageLoading...
Page #150 background image
150
EN
Information
10
Cleaning and storing the camera
Cleaning the camera
Turn off the camera and remove the battery before cleaning the camera.
Exterior:
Wipe gently with a soft cloth. If the camera is very dirty, soak the cloth in mild soapy water
and wring well. Wipe the camera with the damp cloth and then dry it with a dry cloth. If you
have used the camera at the beach, use a cloth soaked in clean water and well wrung.
Monitor:
Wipe gently with a soft cloth.
Lens:
Blow dust off the lens with a commercially available blower. For the lens, wipe gently with
a lens cleaning paper.
Storage
When not using the camera for a prolonged period, remove the battery and card. Store
the camera in a cool, dry place that is well ventilated.
Insert the battery periodically and test the camera’s functions.
Remove dust and other foreign matter from the body and rear caps before attaching them.
Attach the body cap to the camera to prevent dust from getting inside when no lens is
attached. Be sure to replace the front and rear lens caps before putting the lens away.
Clean the camera after use.
Do not store with insect repellent.
Cleaning and checking the image pickup device
This camera incorporates a dust reduction function to keep dust from getting on the
image pickup device and to remove any dust or dirt from the image pickup device
surface with ultrasonic vibrations. The dust reduction function operates when the
camera is turned on.
The dust reduction function operates at the same time as the pixel mapping, which
checks the image pickup device and image processing circuitry. Since dust reduction
is activated every time the camera’s power is turned on, the camera should be held
upright for the dust reduction function to be effective.
Cautions
Do not use strong solvents such as benzene or alcohol, or a chemically treated cloth.
Avoid storing the camera in places where chemicals are treated, in order to protect the
camera from corrosion.
Mold may form on the lens surface if the lens is left dirty.
Check each part of the camera before use if it has not been used for a long time. Before
taking important pictures, be sure to take a test shot and check that the camera works
properly.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus E-M5 Mark II and is the answer not in the manual?

Olympus E-M5 Mark II Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels17.2 MP
Image sensor size4/3 \
Image formats supportedJPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Image stabilizer locationBody
Still image resolution(s)4608x3456, 3200x2400, 1280x960
Lens typeStandard
Filter size62 mm
Optical zoom- x
Focal length range12 - 40 mm
Lens mount interfaceMicro Four Thirds (MFT)
Minimum aperture number-
Number of diaphragm blades7
Lens structure (elements/groups)14/9
Maximum focal length (35mm film equiv)80 mm
Minimum focal length (35mm film equiv)24 mm
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) points800
Auto focusing (AF) modesContinuous Auto Focus, Tracking Auto Focus
Closest focusing distance0.2 m
Light meteringCentre-weighted, Spot
ISO sensitivity100, 200, 1600, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)200
Light exposure controlProgram AE
Light exposure correction±5EV (1/2; 1/3 EV step)
Fastest camera shutter speed1/8000 s
Slowest camera shutter speed60 s
Flash modesAuto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed0.000125 s
Shoe mounting point typeHot shoe
Flash exposure correction±3EV (1/2, 1/3, 1 EV step)
Built-in flashNo
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate60 fps
Video formats supportedAVI, MOV
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@25fps, 1280x720@50fps, 1280x960@30fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 640x480@30fps
Memory slots1
Internal memory- MB
Compatible memory cardsSDHC, SDXC
Display diagonal3 \
Display aspect ratio3:2
Display resolution (numeric)1037000 pixels
Magnification2 x
Viewfinder typeElectronic
USB version2.0
USB connectorMicro-USB B
HDMI connector typeMicro
Scene modesBeach, Candlelight, Children, Documents, Fireworks, Night, Night portrait, Panorama, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editingResizing, Rotating, Trimming
Photo effectsBlack&White, Muted, Sepia, Vivid
White balanceAuto, Custom modes
Shooting modesAperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playbackHighlights, Movie, Single image, Slide show
Self-timer delay2, 3, 5, 10, 12, 20, 30 s
Camera file systemDCF, DPOF, Exif, PRINT Image Matching III, RAW
Compatible productsFL-50R, FL-36R, FL-20, FL-14, FL-300R, FL-600R
Image quality adjustmentSaturation
On Screen Display (OSD) languagesBUL, CHI (SIMPL), CHI (TR), CRO, CZE, DEU, ENG, ESP, EST, FIN, FRE, GRE, HUN, IND, ITA, JPN, KOR, LAV, LIT, NOR, RUM, RUS, SER, SLK, SLV, THA, TUR, UKR
Battery typeBLN-1
Product colorSilver
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)-10 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)30 - 90 %
Cables includedAV, USB
F-number (relative aperture)2.8
Weight and Dimensions IconWeight and Dimensions
Depth44.5 mm
Width123.7 mm
Height85 mm
Weight417 g
Lens length84 mm
Lens weight382 g
Lens diameter69.9 mm
Weight (including battery)469 g
