Olympus E-M5 Mark II User Manual

94 EN
Menu functions (Shooting menus)
4
Keystone correction and perspective control ( Keystone Comp.)
Use keystone correction for shots taken from the bottom of a tall building, or
deliberately exaggerate the effects of perspective. This setting is only available in
P/A/S/M modes.
1
Select [On] for [Keystone Comp.] in X Shooting
Menu 2.
18
mm
2
Adjust the effect in the display and frame the shot.
• Use the front dial or rear dial for keystone correction.
• Use FGHI to choose the area recorded.
• Press and hold the Q button to cancel any changes.
• To adjust exposure compensation and other shooting options while keystone
compensation is in effect, press the INFO button to view a display other than
keystone compensation adjustment. To resume keystone compensation, press the
INFO button until keystone compensation adjustment is displayed.
3
Shoot.
• To end keystone compensation, select [Off] for [Keystone Comp.] in X Shooting
Menu 2.
$ Notes
• When [D (Keystone compensation)] (P. 67) is assigned to a button using [Button Function],
press and hold the selected button to end keystone correction.
Cautions
• Photos are recorded in RAW + JPEG format when [RAW] is selected for image quality.
• The desired results may not be obtained with converter lenses.
• Depending on the amount of correction, some AF targets may be outside the display
area. An icon (g, h, i or j) is displayed when the camera focuses on an AF target
outside the display area.
• The following are not available during digital shift photography:
live bulb, live time, or composite photography/sequential shooting/bracketing/HDR/
multiple exposure/digital tele-converter/movie/[C-AF] and [C-AF+TR] autofocus modes/
full-time AF/[e-Portrait] and ART picture modes/custom self-timer/peaking/high
resolution shot
• If a focus distance is selected for [Image Stabilizer], the correction will be adjusted for
the selected focus distance. Except when using a Micro Four Thirds or Four Thirds lens,
choose a focal length using the [Image Stabilizer] (P. 57) option.

Olympus E-M5 Mark II Specifications

General

Megapixel	16.1 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	17.2 MP
Image sensor size	4/3 \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Image stabilizer location	Body
Still image resolution(s)	4608x3456, 3200x2400, 1280x960
Lens type	Standard
Filter size	62 mm
Optical zoom	- x
Focal length range	12 - 40 mm
Lens mount interface	Micro Four Thirds (MFT)
Minimum aperture number	-
Number of diaphragm blades	7
Lens structure (elements/groups)	14/9
Maximum focal length (35mm film equiv)	80 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	800
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Closest focusing distance	0.2 m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 1600, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	200
Light exposure control	Program AE
Light exposure correction	±5EV (1/2; 1/3 EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.000125 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Built-in flash	No
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	AVI, MOV
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1280x960@30fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 640x480@30fps
Memory slots	1
Internal memory	- MB
Compatible memory cards	SDHC, SDXC
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1037000 pixels
Magnification	2 x
Viewfinder type	Electronic
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Scene modes	Beach, Candlelight, Children, Documents, Fireworks, Night, Night portrait, Panorama, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Resizing, Rotating, Trimming
Photo effects	Black&White, Muted, Sepia, Vivid
White balance	Auto, Custom modes
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Self-timer delay	2, 3, 5, 10, 12, 20, 30 s
Camera file system	DCF, DPOF, Exif, PRINT Image Matching III, RAW
Compatible products	FL-50R, FL-36R, FL-20, FL-14, FL-300R, FL-600R
Image quality adjustment	Saturation
On Screen Display (OSD) languages	BUL, CHI (SIMPL), CHI (TR), CRO, CZE, DEU, ENG, ESP, EST, FIN, FRE, GRE, HUN, IND, ITA, JPN, KOR, LAV, LIT, NOR, RUM, RUS, SER, SLK, SLV, THA, TUR, UKR
Battery type	BLN-1
Product color	Silver
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Cables included	AV, USB
F-number (relative aperture)	2.8

Weight and Dimensions

Depth	44.5 mm
Width	123.7 mm
Height	85 mm
Weight	417 g
Lens length	84 mm
Lens weight	382 g
Lens diameter	69.9 mm
Weight (including battery)	469 g
