48
EN
Shooting
2
Setting the AF target (AF Area)
Choose which of the 81 autofocus targets will be used for autofocus.
1
Press the arrow pad to display the AF target.
2
Use FGHI to change to single target display and select the AF position.
“All targets” mode is restored if you move the cursor off the screen.
All Targets
Single Target
All Targets
The camera automatically
chooses from the full set of
focus targets.
Select the focus target
manually.
Cautions
When using a Four Thirds system lens, the camera automatically switches to single target
mode.
The size and number of the AF target changes depending on the [Digital Tele-converter],
[Image Aspect], and group target settings.
Using small target and group target (Setting AF target)
You can change the target selection method and target size. You can also select Face
priority AF (P. 49 ).
1
Press the arrow pad to display the AF target.
2
Press the INFO button during AF target selection and choose a selection
method using FG.
INFO
ii
o
FG
ii
o
(All Targets)
The camera selects automatically from among all the AF
targets.
I
(Single Target)
You select a single AF target.
K
(Small Target)
The AF target can be reduced in size.
J
(Group Target)
The camera automatically chooses from the targets in the
selected group.
Cautions
When shooting movies, the camera automatically switches to single target mode.
When using a Four Thirds system lens, the camera automatically switches to single target
mode.
