Olympus E-M5 Mark II User Manual

37 EN
Shooting
2
Choosing aperture and shutter speed (M manual mode)
Mode M is a shooting mode where you choose both the aperture and shutter speed.
They can be set even in bulb, time, and live composite photography, where the shutter
remains open while the shutter button is pressed. Set the mode dial to M.
• The exposure determined by the aperture value and
shutter speed you have set, and the difference relative
to a suitable exposure measured by the camera are
displayed on the monitor.
• Shutter speed can be set to values between 1/8000
and 60 seconds or to [BULB] or [LIVE TIME], or
[LIVECOMP].
Difference from correct
exposure
250250 F5.6
01:02:0301:02:03
3838
L
N
M
0.00.0
ISO
400
FullHD
F
S-IS AUTO S-IS AUTO
Wi-Fi
Front dial
Lever
Rear dial
Dial
Position of the lever
12
r
Aperture value ISO
o
Shutter speed White balance
Cautions
• If you change the aperture value and shutter speed, the display on the monitor (or
viewfi nder) will not change. To display the image as it is going to be shot, set [Live View
Boost] (P. 102) in Custom Menu.
• Even when you have set [Noise Reduct.], noise and/or light spots may still be noticeable
in the image displayed on the monitor and shot images under certain environmental
conditions (temperature etc.) and camera settings.
Noise in images
While shooting at slow shutter speeds, noise may appear on screen. These phenomena
occur when the temperature rises in the image pickup device or image pickup device
internal drive circuit, causing current to be generated in those sections of the image pickup
device that are not normally exposed to light. This can also occur when shooting with a
high ISO setting in a high-temperature environment. To reduce this noise, the camera
activates the noise reduction function. g [Noise Reduct.] (P. 104 )
Shooting with long exposure time (BULB)
Use for night landscapes and fi reworks. In M mode, set the shutter speed to [BULB] or
[LIVE TIME].
Bulb photography (BULB): The shutter remains open while the shutter button is pressed.
The exposure ends when the shutter button is released.
Time photography (TIME): The exposure begins when the shutter button is pressed all
the way down. To end the exposure, press the shutter button
all the way down again.
• During bulb, time, or live composite photography, the screen brightness changes
automatically. g “Bulb/Time Monitor” (P. 104)

Olympus E-M5 Mark II Specifications

General

Megapixel	16.1 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	17.2 MP
Image sensor size	4/3 \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Image stabilizer location	Body
Still image resolution(s)	4608x3456, 3200x2400, 1280x960
Lens type	Standard
Filter size	62 mm
Optical zoom	- x
Focal length range	12 - 40 mm
Lens mount interface	Micro Four Thirds (MFT)
Minimum aperture number	-
Number of diaphragm blades	7
Lens structure (elements/groups)	14/9
Maximum focal length (35mm film equiv)	80 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	800
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Closest focusing distance	0.2 m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 1600, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	200
Light exposure control	Program AE
Light exposure correction	±5EV (1/2; 1/3 EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.000125 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Built-in flash	No
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	AVI, MOV
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1280x960@30fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 640x480@30fps
Memory slots	1
Internal memory	- MB
Compatible memory cards	SDHC, SDXC
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1037000 pixels
Magnification	2 x
Viewfinder type	Electronic
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Scene modes	Beach, Candlelight, Children, Documents, Fireworks, Night, Night portrait, Panorama, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Resizing, Rotating, Trimming
Photo effects	Black&White, Muted, Sepia, Vivid
White balance	Auto, Custom modes
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Self-timer delay	2, 3, 5, 10, 12, 20, 30 s
Camera file system	DCF, DPOF, Exif, PRINT Image Matching III, RAW
Compatible products	FL-50R, FL-36R, FL-20, FL-14, FL-300R, FL-600R
Image quality adjustment	Saturation
On Screen Display (OSD) languages	BUL, CHI (SIMPL), CHI (TR), CRO, CZE, DEU, ENG, ESP, EST, FIN, FRE, GRE, HUN, IND, ITA, JPN, KOR, LAV, LIT, NOR, RUM, RUS, SER, SLK, SLV, THA, TUR, UKR
Battery type	BLN-1
Product color	Silver
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Cables included	AV, USB
F-number (relative aperture)	2.8

Weight and Dimensions

Depth	44.5 mm
Width	123.7 mm
Height	85 mm
Weight	417 g
Lens length	84 mm
Lens weight	382 g
Lens diameter	69.9 mm
Weight (including battery)	469 g
