Olympus E-M5 Mark II User Manual

62 EN
Shooting
2
Selecting image quality (movie image quality mode)
Set a movie image quality mode suitable for the desired use.
1
Set the mode dial to n.
2
Press the Q button to display the live control, and select a movie image
quality mode using the rear dial.
PP
P
P
WB
AUTO
WBWBWB
AUTOAUTOAUTO
n
PP
S-AFS-AF
j
1
M-IS M-IS
FHD
F
60p
FHD
F
30p
FHD
F
60p
FHD
SF
60p
FHD
F
30p
c
FHD
30p
N
FHD
F
30p
MOVFHD60p
F
Movie image quality mode
3
Select an item using the front dial.
• To change the settings in the image quality modes, press the INFO button and
change settings using the rear dial.
Record mode Application Settings you can change
MOVFHD30p
F
(Full HD Fine 30p)*
1
Shooting clips (P. 42)
Frame rate
Shooting time
MOV
n
FHD60p
F
(Full HD Fine 60p)*
1
Setting 1 Frame rate
MOV
n
FHD60p
SF
(Full HD Super Fine 60p)*
1
Setting 2 Frame rate
MOV
n
FHD30p
F
(Full HD Fine 30p)*
1
Setting 3 Frame rate
MOV
n
FHD30p
N
(Full HD Normal 30p)*
1
*
3
Setting 4 Frame rate
MOV
n
FHD30p
F
(Full HD Fine 30p)*
1
Custom
Type of movie, detailed settings,
slow/quick motion shooting
HD
(1280×720, Motion JPEG)*
2
For computer playback
or editing
–
SD
(640×480, Motion JPEG)*
2
For computer playback
or editing
–
*1 File format: MPEG-4 AVC/H.264. Files may be up to 4 GB in size. Individual movies may
be up to 29 minutes in length.
*2 Files may be up to 2GB in size.
*3 All-Intra refers to a movie recorded without inter-frame compression. Movies in this format
are suitable for editing but have a lower compression rate and consequently a larger data
size.
• When Video output is set to PAL, a frame rate of 30p will become 25p and a frame rate of
60p will become 50p.
• Depending on the type of card used, recording may end before the maximum length is
reached.
4
Press the Q button to save changes.

Olympus E-M5 Mark II Specifications

General

Megapixel	16.1 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	17.2 MP
Image sensor size	4/3 \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Image stabilizer location	Body
Still image resolution(s)	4608x3456, 3200x2400, 1280x960
Lens type	Standard
Filter size	62 mm
Optical zoom	- x
Focal length range	12 - 40 mm
Lens mount interface	Micro Four Thirds (MFT)
Minimum aperture number	-
Number of diaphragm blades	7
Lens structure (elements/groups)	14/9
Maximum focal length (35mm film equiv)	80 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	800
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Closest focusing distance	0.2 m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 1600, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	200
Light exposure control	Program AE
Light exposure correction	±5EV (1/2; 1/3 EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.000125 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Built-in flash	No
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	AVI, MOV
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1280x960@30fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 640x480@30fps
Memory slots	1
Internal memory	- MB
Compatible memory cards	SDHC, SDXC
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1037000 pixels
Magnification	2 x
Viewfinder type	Electronic
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro
Scene modes	Beach, Candlelight, Children, Documents, Fireworks, Night, Night portrait, Panorama, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Resizing, Rotating, Trimming
Photo effects	Black&White, Muted, Sepia, Vivid
White balance	Auto, Custom modes
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Self-timer delay	2, 3, 5, 10, 12, 20, 30 s
Camera file system	DCF, DPOF, Exif, PRINT Image Matching III, RAW
Compatible products	FL-50R, FL-36R, FL-20, FL-14, FL-300R, FL-600R
Image quality adjustment	Saturation
On Screen Display (OSD) languages	BUL, CHI (SIMPL), CHI (TR), CRO, CZE, DEU, ENG, ESP, EST, FIN, FRE, GRE, HUN, IND, ITA, JPN, KOR, LAV, LIT, NOR, RUM, RUS, SER, SLK, SLV, THA, TUR, UKR
Battery type	BLN-1
Product color	Silver
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %
Cables included	AV, USB
F-number (relative aperture)	2.8

Weight and Dimensions

Depth	44.5 mm
Width	123.7 mm
Height	85 mm
Weight	417 g
Lens length	84 mm
Lens weight	382 g
Lens diameter	69.9 mm
Weight (including battery)	469 g
