Olympus FL-700WR - Names of Parts

37
EN
Names of Parts
1
2
g
3
4
9
0
5
f
h
6
e
a
i
8
7
c
d
j
b
1 Control panel ................................ P. 38
2 MODE button .......................... P. 42, 52
3 CHARGE/TEST button ................. P. 41
4 Latch ............................................. P. 40
5 Latch release button ..................... P. 40
6 #/l (radio communication mode
switching) button ..................... P. 42, 52
7 ON/OFF button ............................. P. 41
8 OK button ................................ P. 42, 52
9 PUSH (lock release) button .......... P. 47
0 Battery compartment cover ...........P. 39
a Catch light plate ............................ P. 48
b Wide panel .................................... P. 48
c Flash window ................................ P. 47
d AF illuminator/LED light .......... P. 59, 60
e Optical communication sensor
window .......................................... P. 49
Dial/Arrow pad
f Dial .................................... P. 42, 52, 59
g a (flash compensation/flash intensity)/
H button ............... P. 43, 44, 45, 46, 52
h MENU/b (key locking)/G button
...................................................... P. 59
i ZOOM/F button
........................ P. 43, 44, 45, 46, 47, 52
j LED/I button ............................... P. 59
