OEP-3 V1 (UC)
Remarks:
This signal is used for control of a relay switch on the IF-764 board.
Video mode (IF-767 board)
Purpose
Confirms the video mode set by the user.
Remarks:
This mode is connected to the NTSC/PAL set switch on the IF-767 board.
Output video signal
Purpose
Selects an output signal.
THRU_EE Contents
L THROUCH
HEE
SW_NTSC_NPAL Contents
H NTSC
L PAL
