TC--C2 COMPACT TROLLEY
1
1 INTRODUCTION
The TC--C2 is supplied ready for assembly, with all the necessary tools and components. Please refer to Figure 1 below
and confirm that all items in the standard set are present. Contact your Olympus service c entre or nearest Olympus
office if any parts are damaged or missing.
FIGURE 1-1
Instructions
Top shelf
(removable)
Keyboard tray
Second shelf (fixed)
Third shelf (adjustable)
Base tray
Plain castor
Brake castor
M6 hand wheel x2
Scope pole with
umbilical holder
Fixings
Webbing strap x1
5mm ball driver x1
Foot holder x8
Handle
Accessory fixing holes
(all shelves)
Jet nut x1
Scope hanger
4mm A/F Allen key x1
Cable management
Guard Rail RH x1
Guard Rail LH x1
Plugblock
(not all versions)
VISY218
