Chapter 2 Nomenclature and Functions
17
VIDEO SYSTEM OTV-SI
1. Video output terminals (Y/C terminal)
Y/C video signal is transmitted via these terminals.
2. Video output terminal (BNC terminal)
The composite video signal is transmitted via this terminal.
3. System terminal
This terminal is used to service this instrument by OLYMPUS.
4. Hard copy terminal
Communication signals for the color video printer (OEP-3/OEP) are
transmitted via this terminal.
5. VTR remote terminal
The communication signals for the VTR are transmitted via this terminal.
6. Keyboard terminal
Data from the keyboard are transmitted via this terminal.
7. Fuse box
The fuse box protects the video system from electrical surges.
8. AC power inlet
AC power is provided via this inlet.
9. Potential equalization terminal
For safety purposes, this terminal is connected to a potential equalization
busbar of the electrical installation.
