Chapter 3 Installation and Connection
37
VIDEO SYSTEM OTV-SI
Figure 3.9
Video monitor
BNC cable (B) (MB-677)
Y/C cable (MH-985)
INPUT S-VIDEO terminal Remote terminal
Color video printer
(OEP-3/OEP)
OUTPUT
S-VIDEO terminal
Y/C cable (MH-985)
OEP cable (MH-987)
To wall mains outlet
Video system (OTV-SI)
VISY218
