Chapter 3 Installation and Connection
39
VIDEO SYSTEM OTV-SI
Figure 3.10
Y/C cable (MH-985)
SVO-9500MD
Front panel
Input Output
Rear panel
REMOTE 2
S VIDEO IN S VIDEO OUT
VTR remote cable (MAJ-438)
To video monitor
BNC cable (B) (MB-677)
Video system (OTV-SI)
VISY218
