Olympus U-CBS User Manual

POWER

8
CODED FUNCTION SYSTEM
2 BX43 (System with Halogen Lamp Socket U-LSADP + U-LS30-5)
Use 6 cable holders.
Align with the top right
corner of the label.
Banding band
(Provided with U-HSEXP)
* Only either cable should be used.
Align with the top left
corner of the label.
Remove lamp cable slack
before closing the holder.
Align with the height of
line drawn on the label.
U-D7RES cable
BX3-RFAS cable
RS-232C cable
U-LS30-5
lamp cable
U-HSEXP cable for
right side installation
*
U-HSEXP cable for
left side installation
*
AC adapter cable
